• Spring loaded dead man’s control enables safe, controlled lifting/lowering of vehicle.
• Handle locks in position and can be used at three different angles to allow improved manoeuvrability and access around the vehicle.
• Ideal for workshop or roadside use, takes the effort out of lifting heavy plant, tractors and commercial vehicles.
• Supplied with 45mm and 75mm extensions to help close the gap between the saddle of the jack and the jacking point.
• Handle locks in position and can be used at three different angles to allow improved manoeuvrability and access around the vehicle.
• Ideal for workshop or roadside use, takes the effort out of lifting heavy plant, tractors and commercial vehicles.
• Supplied with 45mm and 75mm extensions to help close the gap between the saddle of the jack and the jacking point.
Specification
| Name | Value |
|---|---|
| Model No | YAJ301 |
| Nett Weight | 47kg |
| Minimum Saddle Height | 210mm |
| Capacity | 30tonne |
| Working Pressure | 116-174psi |
| Air Consumption | 10.5cfm |
| Chassis Length | 490mm |
| Extensions | 45/75mm |
| Maximum Length | 1700mm |
| Overall Width | 290mm |
| Piston Stroke | 133mm |
| Maximum Height (inc. Extension)/capacity-stage 1 (mm/tonne) | 463/30 |
| Maximum Height (inc. Extension)/capacity-stage 2 (mm/tonne) | n/a |
| Maximum Height (inc. Extension)/capacity-stage 3 (mm/tonne) | n/a |
| Width Without Wheels | 176mm |
| Screw Extension | n/a |
SKU: YAJ301
Manufacturer part code: YAJ301
