• Approved to EU and UK Lifting Gear Regulations.
• This hoist is intended for use where a suitable support facility exists.
• Support brackets are included with the equipment.
• The support bar is not included.
• This hoist is intended for use where a suitable support facility exists.
• Support brackets are included with the equipment.
• The support bar is not included.
Specification
| Name | Value |
|---|---|
| Model No | PH400 |
| Nett Weight | 16.0kg |
| Current | 3.3A |
| Voltage | 230V~50Hz |
| Motor Power | 750W |
| Ip Rating | IP54 |
| Capacity (double Cable) | 400kg |
| Capacity (single Cable) | 200kg |
| Lift Speed (maximum) | 8m/min |
| Group Of Mechanisms | M1 |
| Insulating Grade | B |
| Lift Height (double Cable) | 6m |
| Lift Height (single Cable) | 12m |
| Minimum Rope Tensile Strength | 1770N/mm² |
| Rope Diameter | 3.8mm |
| Work Rate | S3 |
SKU: PH400
Manufacturer part code: PH400
