• Approved to EU and UK Lifting Gear Regulations.
• This hoist is intended for use where a suitable support facility exists.
• Support brackets are included with the equipment.
• N.B. Support bar is not included.
• This hoist is intended for use where a suitable support facility exists.
• Support brackets are included with the equipment.
• N.B. Support bar is not included.
Specification
| Name | Value |
|---|---|
| Model No | PH250 |
| Nett Weight | 9.6kg |
| Current | 2.2A |
| Voltage | 230V~50Hz |
| Motor Power | 500W |
| Ip Rating | IP54 |
| Capacity (double Cable) | 250kg |
| Capacity (single Cable) | 125kg |
| Lift Speed (maximum) | 8m/min |
| Group Of Mechanisms | M1 |
| Insulating Grade | B |
| Lift Height (double Cable) | 6m |
| Lift Height (single Cable) | 12m |
| Minimum Rope Tensile Strength | 1870N/mm² |
| Rope Diameter | 3mm |
| Work Rate | S3 |
SKU: PH250
Manufacturer part code: PH250
