• Manufactured using high quality components for performance and reliability.
• Made from heavy-duty die-cast magnesium alloy with a variable speed gearbox for greater accuracy.
• Fitted with a powerful magnet to ensure unit stays adhered at any angle.
• Uses a double dovetail groove to increase the stroke length.
• Includes safety fixing strap and integrated coolant system.
• Can be used with a 16mm twist drill chuck and M8 to M20 Tapping chucks.
• Designed for use in fabrication, construction and other applications when drilling/tapping ferrous metal.
• Made from heavy-duty die-cast magnesium alloy with a variable speed gearbox for greater accuracy.
• Fitted with a powerful magnet to ensure unit stays adhered at any angle.
• Uses a double dovetail groove to increase the stroke length.
• Includes safety fixing strap and integrated coolant system.
• Can be used with a 16mm twist drill chuck and M8 to M20 Tapping chucks.
• Designed for use in fabrication, construction and other applications when drilling/tapping ferrous metal.
Specification
| Name | Value |
|---|---|
| Model No | MAG60230VHD |
| Nett Weight | 22.50kg |
| Supply | 230V~50Hz |
| Motor Power | 1880W |
| Motor Power | 1880W |
| Power Supply | 220V – 50Hz |
| Stroke Length | 220mm |
| Magnet Adhesion | 17000N |
| Maximum Cutter Depth | 50mm |
| Maximum Annular Cutter Capacity | 60mm |
| Cutting Depth | 50mm |
| No-Load Speed | 220/380rpm |
| No-Load Speed | 0-380rpm |
| Magnetic Adhesion | 17000N |
| Core Drill Diameter | 60mm |
| Morse Taper | MT3 |
| Twist Drill Diameter | 23mm |
| Tapping Drill Diameter | M8 – M20 |
SKU: MAG60230VHD
Manufacturer part code: MAG60230VHD
